Kingdream rotary buttons bits IADC 517 for oil well
The advantage of using a tricone bit
1. There is a tri cone suitable for any formation2. Tricone bits are versatile and can handle changing formations
3. Tricones are reasonably priced with long life and good rate of drilling
Depending on ur application,we can provide u with new,rerun or premium oil field quality tricone bits,
the difference between a premium oil field tricone bit and nonpremium oil well quality tricone is that the roller cones have high end sealed bearings: extremely high quality tungsten carbide and offer diamond gauge protection throughout the drill bit. These roller cone bits are designed to go to extreme depths in extreme conditions and in situations where they cannot fail.
Our tci tricone bit range in size from 3” to 26”
Our mill tooth tricone bit range in size from 3” to 26”
The main structure parameter of tricone bits
Bit sizes | Std API pin shank(inches) | Jet nozzle size (mm) | |||
mm | Inches | Diamter | Length | Nozzle diameter | |
95.2-107.9 | 3 3/4-4 1/4 | 2 3/8REG | 20.3 | 17.5 | 4-10 |
120.6 | 4 3/4 | 2 7/8REG | |||
142.9-171.4 | 5 5/8-6 3/4 | 3 1/2REG | 23.6 | 19 | 5-16 |
190.5-200.0 | 7 1/2-7 7/8 | 4 1/2REG | 29.8 | 19 | 7-18 |
212.7-222.2 | 8 3/8-8 3/4 | 4 1/2REG | 33 | 27 | 8-20 |
241.3-311.1 | 9 1/2-12 1/4 | 6 5/8REG | |||
444.5-660.4 | 17 1/2-26 | 7 5/8REG | 33(41) | 27 | 8-20 |
Suitable formations:
Rock formation | Bit type | Bit size | Drilling weight | Rotary speed | ||
mm | inch | N/mm | r/mm | |||
Very soft | Soft marl, clays, sands, salts etc. | 1 | 187.3-346.1 | 7 3/8-13 5/8 | 441-735 | 120-50 |
444.5-660.4 | 17 1/2-26 | 196-686 | 90-60 | |||
Soft | Clays, soft shale, marl, sands, salts etc. | 2 | 95.2-174.6 | 3 3/4-6 7/8 | 245-490 | 100-50 |
187.3-346.1 | 7 3/8 13 5/8 | 490-784 | 90-40 | |||
444.5-660.4 | 17 1/2-26 | 196-686 | 60-40 | |||
Medium soft | Shale, marl sandstone, soft limestone etc. | 3 | 95.2-174.6 | 3 3/4-6 7/8 | 245-490 | 90-50 |
187.3-311.1 | 7 3/8-12 1/4 | 490-784 | 80-40 | |||
444.5-660.4 | 17 1/2-26 | 196-686 | 60-40 | |||
medium | Hard shale , limestone, medium/hard sandstone etc | 4 | 95.2-174.6 | 3 3/4-6 7/8 | 294-539 | 80-60 |
187.3-241.1 | 7 3/8-9 1/2 | 539-833 | 60-40 | |||
