Best 152mm 6inch 5 blades Steel body PDC bit foroil and gas drilling equipment,drilling

API &ISO Best PDC Drill Bit 152mm Diamond Drill Bit Manufacture

Bit Type	152mm
IADC Code	323
Blade	5
Cutter Size (mm)	Φ16mm; Φ13mm
Cutter Qty	Φ16×47;Φ13×10
Nozzle Qty/Type	5NZ
Gauge Length (mm)	80
Connection	3 1/2” API REG
N.W./ G.W.(KG)	35
Nozzle Size (inch)	16/32;18/32



Specifications

1) Our bits are certified by ISO9001&API

2) Our pdc bits have fast drilling rate

3) Our pdc bits possess strong cutting structure

Packaging & Delivery



Packing Details: wooden box, metal box or as your requirement



Delivery Details: within 15 workdays



PDC bits series



1)Feature : We have improved our PDC bit support and retention.



2) Advantage : Our PDC bits can manage the magnitude cutter loading and bit torque.



3)Benefit : We have improved the durability and directional responsiveness of our PDC bits.





Detailed Product Description



1) We are PDC diamond drill bits manufacturer. There is no middleman between us. We sell the



productsdirectly to you. Therefore the price of our bits is very reasonable and competative.



2) We have many years of designing and producing experience, advanced producing equipement and



techonology. We adopt the mechanized production, which is of high efficiency and high quality.



3) Our PDC diamond drill bits are well sold both at home and abroad.We have established successful



cooperation with many drill bits companies and oil companies.



4). Cutting structure is force balanced and bit blade is asymmetrically designed so that the load on bit



isbalanced that resultingbetter stability of the bit.



5) The experienced and knowledgeable service team will ensure the superior performance of our



productsin both the domesticand international markets.





6) Cutter exposure is optimized to insure the oil bit can achieve higher ROP is soft to medium



formations.





7). Shock absorbers are designed to make the bit capable of drilling through formations with hard



strigers.





8). Hydraulic system of the bit is optimized using dynamic flow pattern simulation technology to



enhancecleaning and coolingeffects of the bit to effectively prevent bit from balling.



9) We also sell semi-finished PDC drill bits.



Features



1)Size

3" -26" inch, as your request



2)Type

PDC bits and diamond core bit



3)Application

water well, oil field, construction, geothermal, directional boring, and underground foundation are all avillable for PDC bit



4)Formation

Sticky, soft, medium, medium-hard, hard formation have there suitable pdc bit



5)Delivery Time

According to the amount of pdc bits you require
